COEUR STAINLESS
High quality stainless steel bolt hanger for typical exterior uses (pack of 20)
High quality stainless steel bolt hanger for typical exterior uses. It is available for 10 or 12 mm diameter bolts.
Detailed description
Description
- 316L stainless steel offers excellent resistance to corrosion in typical exterior environments
- Easy clipping:
- the wide, ergonomic connection hole facilitates carabiner clipping
- the width of the hole allows installation of two carabiners at the same time - Prevents wear of connectors: the thickness of the hanger and the rounded edges of the connection hole limit wear of connectors
- Hanger anti-rotation system: textured back keeps the hanger from turning when the anchor is being installed or when it is heavily laterally loaded during use
- Available for 10 or 12 mm bolts
Specifications
- Material(s): 316L stainless steel
- Certification(s): EN 795 A, GB 30862/A
References
| References | P36AS 10 | P36AS 12 |
|---|---|---|
| Diameter | 10 mm | 12 mm |
| Weight | 65 g | 60 g |
| Guarantee | 3 years | 3 years |
| Inner Pack Count | 1 | 1 |
Technical information
Technical notice
- Download the PDF : technical-notice-COEUR-BOLT-STEEL-STAINLESS-HCR-1 - 2.33 MB
Declaration Of Conformit
- Download the PDF : Declaration of conformity-P36AS 10_12-Coeur Stainless - 0.11 MB
